Wegner Automotive LSX GM LSA 1.9L Drive Kit | LSA, Camaro, Truck Offset
WAK053 GM LSA 1.9L
LSA Drive
This LSA drive kit was engineered for high performance street use with key features such as:
- Supercharger runs on dedicated 8 rib belt for max overdrive
- Runs SC on OE LSA alignment so you can run stock damper and SC pulley for stock boost
- Max pulley belt wrap for NO slip, extra idler pulley to give power steering complete wrap
- Rigid design eliminates component flex
- Internal fan alternator cools better while also allowing for more RPM
- High quality & heavy duty components
- CAD designed & CNC machined brackets & pulleys
- Drive will support SC pulleys for up to 875 HP
- Runs OE water pump
- Drive will work with 90mm & 102mm DBW Throttle Body
All our accessory drives are built to order - please allow 4-6 weeks for delivery
Note: Only Billet components would come in custom finish. Factory components would come in factory finish.
Our base WAK047 Accessory Drive includes the following -
- Heavy Duty Gates Belt Tensioners
- Standard Internal Fan 170 Amp 1 Wire or GM 2 pin Late Model Powermaster Alternator (Upgrade to 225 or 370)
- GM Type 2 Power Steering Pump
- OE LSA / LS3 Water Pump
- OE Sanden SD7 AC Compressor
- All necessary Wegner Automotive precision CNC Machined Billet brackets, Pulleys, and Stainless-Steel Mounting Hardware
Crank Pulley
Utilizes OEM LSA crank pulley
Options:
ATI damper crank pulley
Supercharger pulley diameter: OEM, 5%, 11%, 15%, or 18.5% overdrive
Power steering pump
GM Type II Style PS Pump
Options:
- Attached PS Pump reservoir (standard) Optional fittings (6AN, 10AN) for Remote Res.
Alternator
170 Amp single wire or GM 2 pin with internal fan
Optional: 225 or 370 Amp upgrade
Finish Color
- Solid Black
- Machined Aluminum
- Two-Tone Diamond Cut ($100)
- Polished Aluminum($300)
Optional Alternator
- 170 Amp Powermaster
- 225 Amp Powermaster ($150)
- 370 Amp Mechman ($300)
Power Steering Reservoir
- Power Steering Reservoir Attached to Pump
- Power Steering -6,-10 A/N fittings for Remote Mount
Air Conditioning
Sanden SD7 AC Compressor
Supercharger Pulleys
- Multiple sizes available depending on engine build and desired boost
